Membrane materials and pore sizes

Membrane materials and pore sizes

Inopor offers microfiltration membranes designed for abrasive conditions:

The ceramic support is made out of α-Al₂O₃. Our membranes are available in lengths of 100 mm up to 1200 mm.

^* Because of technological developments related to the products, systems, and/or services described herein, the data and procedures are subject to change without notice. Please consult your inopor representative or visit www.inopor.com to verify that this information remains valid.
^** As end use conditions can vary, it is the users responsibility to verify compatibility with their specific use conditions.

Geometries

Geometries

		Outer Diameter	Channel Diameter	Channels	spec. Membrane Area	Membrane Area (1200 mm length)	spec. Crossflow Velocity
item		[mm]	[mm]	number	[m2 m]	[m2]	[m3/h m/s]
	AA	10.0	7.0	1	0.022	0.026	0.14
	AB	20.3	15.5	1	0.049	0.058	0.68
	BA	25.0	6.0	7	0.132	0.158	0.71
	LA	25.0	7x uni 1x 6	8	0.188	0.193	0.77
	CA	25.0	3.5	19	0.209	0.251	0.66
	CB	41.4	6.0	19	0.358	0.430	1.93
	GA	25.0	3.0	31	0.315	0.351	0.85
	MC	41.0	3.8	37	0.490	0.576	1.84
	EB	26.4	2.0	61	0.426	0.512	0.85
	EC	25.0	2.0	61	0.383	0.460	0.69
	EE	41.0	3.4	61	0.722	0.867	2.43
	HA	41.0	2.0	163	1.098	1.317	2.11

Depending on the type of end sealing the outer diameter might be bigger. Glass and ceramic could be chosen for end sealing of the ceramic support. The outer diameter will increase as followed:

• glass: outer diameter + 0.3 mm
• ceramic: outer diameter + 0.1 mm
